P2.98-In/out-rental-576mm
Vegoo
P2.98Indoor or Outdoor 576x576mm Customized Mobile Indoor HD Full color Rental LED Display Screen for Concert/Conferences/Exhibitions.
Model:
Out: P2.98 / P3.6 / P4.5 / P4.8
The LED rental display screen, as a customized die cast aluminum box design, is characterized by its lightness, thinness, and fast installation. The lightweight, quick installation, removal, and transportation of the box are suitable for large-scale leasing and fixed installation applications. You can freely play videos, graphics, and other programs, and broadcast various information in real-time, synchronous, and clear ways. Realistic colors and strong adaptability.
Feature:
High-precision die-casting aluminum cabinet
Cabinet size:576*576*84mm ,Weight:8.8kg
Two design:Flat cabinet/carved cabinet
Regardless of left and right Modules
Refresh Rate: In:3840-7680Hz / Out:7680Hz-10000Hz
White Balance Brightness: In: 600-1000cd / Out: 3000-4500cd
LED rental display screens are lightweight, have a thin structure, and have lifting and quick installation functions, which can meet the requirements of fast installation, disassembly, and transportation for rental occasions; Easy to load and unload, easy to operate, whole screen loading and unloading rely on quick bolt fixation and connection, which can accurately and quickly frame and disassemble the screen, and can assemble different shapes to meet on-site requirements; Unique technology: The unique welding process optimized structural design avoids the on-site malfunction caused by poor contact of electronic product solder joints due to frequent handling;
Lightweight, ultra-thin, and fast installation design, it can complete the installation and disassembly of the display screen in a short time.
Parameter:
PixelPitch | Outdoor-2.98mm | Indoor-2.98mm | |||
Scan Mode | 32s | 32s | |||
Pixel Structure | 3IN1 SMD | 3IN1 SMD | |||
Pixel Density | 111111/m | 111111/m | |||
Module Resolution | 96×96 dots | 96×96 dots | |||
Module Size(WXH) | 288mmx288mm | 288mmx288mm | |||
White Balance Brightness | ≥3000cd/m | ≥720-1000cd /m | |||
Color Temperature | 6500K-12500K | 6500K-12500K | |||
Horizontal Viewing Angle | ≥160° | ≥160° | |||
Vertical Viewing Angle | ≥120° | ≥120° | |||
Optimal Viewing Distance | ≥6meters | ≥6meters | |||
Contrast | ≥5000:1 | ≥5000:1 | |||
Grayscale | 12-14Bit | 12-14Bit | |||
Refresh Rate | 7680Hz-10000Hz | 3840Hz-7680Hz | |||
Continuous Working Time | ≥72H | ≥72H | |||
LifeSpan | 100,000H | 100,000H | |||
Protection Class | IP65 | IP43 | |||
Operating Voltage | DC4.2-5V | DC4.2-5V | |||
Maximum Power Consumption | 750W/m | 600W/m | |||
Average Power Consumption | 240W/m² | 240W/m² |
P2.98Indoor or Outdoor 576x576mm Customized Mobile Indoor HD Full color Rental LED Display Screen for Concert/Conferences/Exhibitions.
Model:
Out: P2.98 / P3.6 / P4.5 / P4.8
The LED rental display screen, as a customized die cast aluminum box design, is characterized by its lightness, thinness, and fast installation. The lightweight, quick installation, removal, and transportation of the box are suitable for large-scale leasing and fixed installation applications. You can freely play videos, graphics, and other programs, and broadcast various information in real-time, synchronous, and clear ways. Realistic colors and strong adaptability.
Feature:
High-precision die-casting aluminum cabinet
Cabinet size:576*576*84mm ,Weight:8.8kg
Two design:Flat cabinet/carved cabinet
Regardless of left and right Modules
Refresh Rate: In:3840-7680Hz / Out:7680Hz-10000Hz
White Balance Brightness: In: 600-1000cd / Out: 3000-4500cd
LED rental display screens are lightweight, have a thin structure, and have lifting and quick installation functions, which can meet the requirements of fast installation, disassembly, and transportation for rental occasions; Easy to load and unload, easy to operate, whole screen loading and unloading rely on quick bolt fixation and connection, which can accurately and quickly frame and disassemble the screen, and can assemble different shapes to meet on-site requirements; Unique technology: The unique welding process optimized structural design avoids the on-site malfunction caused by poor contact of electronic product solder joints due to frequent handling;
Lightweight, ultra-thin, and fast installation design, it can complete the installation and disassembly of the display screen in a short time.
Parameter:
PixelPitch | Outdoor-2.98mm | Indoor-2.98mm | |||
Scan Mode | 32s | 32s | |||
Pixel Structure | 3IN1 SMD | 3IN1 SMD | |||
Pixel Density | 111111/m | 111111/m | |||
Module Resolution | 96×96 dots | 96×96 dots | |||
Module Size(WXH) | 288mmx288mm | 288mmx288mm | |||
White Balance Brightness | ≥3000cd/m | ≥720-1000cd /m | |||
Color Temperature | 6500K-12500K | 6500K-12500K | |||
Horizontal Viewing Angle | ≥160° | ≥160° | |||
Vertical Viewing Angle | ≥120° | ≥120° | |||
Optimal Viewing Distance | ≥6meters | ≥6meters | |||
Contrast | ≥5000:1 | ≥5000:1 | |||
Grayscale | 12-14Bit | 12-14Bit | |||
Refresh Rate | 7680Hz-10000Hz | 3840Hz-7680Hz | |||
Continuous Working Time | ≥72H | ≥72H | |||
LifeSpan | 100,000H | 100,000H | |||
Protection Class | IP65 | IP43 | |||
Operating Voltage | DC4.2-5V | DC4.2-5V | |||
Maximum Power Consumption | 750W/m | 600W/m | |||
Average Power Consumption | 240W/m² | 240W/m² |
The Panels is new high-performance indoor HD LED display incorporating professional industrial design.Die cast aluminum makes it lightweight and strong. The module uses Multi-Color's newest anti-glare black LED to get a high contrast ratio. The innovative and friendly design supports a convenient installation for both hanging and stacking which makes it the ideal solution for large events, concert tours and exhibitions. The finest pixel pitch and outstanding color processing ensures a high-end performance in TV studios and lecture halls.
VG one Dimensions:
Cabinet size:576*576*84mm Weight:8.8kg
Product Features
1.Cabinet corner protection design,the module can be well protected during handling to prevent collision
2. Cabinet support upper and lower staggered splicing
3. Indoor/outdoor modules can be used anywhere, regardless of the left or right;
The same cabinet can be used indoor/outdoor modules of different specifications without replacing any parts.
4.Use the latest optimized module connector,prevent module installation error,easier installation and more stable use
5.Patent curve lock,High precision and simple operation,able to achieve an curve of 5 ° inside and outside
1. Floor mounted:
2. Hoisting installation:
3. Wall installation:
The Panels is new high-performance indoor HD LED display incorporating professional industrial design.Die cast aluminum makes it lightweight and strong. The module uses Multi-Color's newest anti-glare black LED to get a high contrast ratio. The innovative and friendly design supports a convenient installation for both hanging and stacking which makes it the ideal solution for large events, concert tours and exhibitions. The finest pixel pitch and outstanding color processing ensures a high-end performance in TV studios and lecture halls.
VG one Dimensions:
Cabinet size:576*576*84mm Weight:8.8kg
Product Features
1.Cabinet corner protection design,the module can be well protected during handling to prevent collision
2. Cabinet support upper and lower staggered splicing
3. Indoor/outdoor modules can be used anywhere, regardless of the left or right;
The same cabinet can be used indoor/outdoor modules of different specifications without replacing any parts.
4.Use the latest optimized module connector,prevent module installation error,easier installation and more stable use
5.Patent curve lock,High precision and simple operation,able to achieve an curve of 5 ° inside and outside
1. Floor mounted:
2. Hoisting installation:
3. Wall installation:
