P2.98 Indoor/Outdoor Rental LED Display 576x576mm

Availability:
Quantity:
  • P2.98-In/out-rental-576mm

  • Vegoo

P2.98Indoor or Outdoor 576x576mm Customized Mobile Indoor HD Full color Rental LED Display Screen for Concert/Conferences/Exhibitions.


Model:

In: P2.25 / P2.98 / P3.6

Out: P2.98 / P3.6 P4.5 P4.8

The LED rental display screen, as a customized die cast aluminum box design, is characterized by its lightness, thinness, and fast installation. The lightweight, quick installation, removal, and transportation of the box are suitable for large-scale leasing and fixed installation applications. You can freely play videos, graphics, and other programs, and broadcast various information in real-time, synchronous, and clear ways. Realistic colors and strong adaptability.


Feature:

  • High-precision die-casting aluminum cabinet

  • Cabinet size:576*576*84mm ,Weight:8.8kg

  • Two design:Flat cabinet/carved cabinet

  • Regardless of left and right Modules

  • Refresh Rate: In:3840-7680Hz / Out:7680Hz-10000Hz

  • White Balance Brightness: In: 600-1000cd / Out: 3000-4500cd


LED rental display screens are lightweight, have a thin structure, and have lifting and quick installation functions, which can meet the requirements of fast installation, disassembly, and transportation for rental occasions; Easy to load and unload, easy to operate, whole screen loading and unloading rely on quick bolt fixation and connection, which can accurately and quickly frame and disassemble the screen, and can assemble different shapes to meet on-site requirements; Unique technology: The unique welding process optimized structural design avoids the on-site malfunction caused by poor contact of electronic product solder joints due to frequent handling;

Lightweight, ultra-thin, and fast installation design, it can complete the installation and disassembly of the display screen in a short time.


Parameter:

PixelPitch Outdoor-2.98mm Indoor-2.98mm
Scan Mode 32s 32s
Pixel Structure 3IN1 SMD 3IN1 SMD
Pixel Density 111111/m 111111/m
Module Resolution 96×96 dots 96×96 dots
Module Size(WXH) 288mmx288mm 288mmx288mm
White Balance Brightness ≥3000cd/m ≥720-1000cd /m
Color Temperature 6500K-12500K 6500K-12500K
Horizontal Viewing Angle ≥160° ≥160°
Vertical Viewing Angle ≥120° ≥120°
Optimal Viewing Distance ≥6meters ≥6meters
Contrast ≥5000:1 ≥5000:1
Grayscale 12-14Bit 12-14Bit
Refresh Rate 7680Hz-10000Hz 3840Hz-7680Hz
Continuous Working Time ≥72H ≥72H
LifeSpan 100,000H 100,000H
Protection Class IP65 IP43
Operating Voltage DC4.2-5V DC4.2-5V
Maximum Power Consumption 750W/m 600W/m
Average Power Consumption 240W/m² 240W/m²



微信图片_20240316172823


Specification:


The Panels is new high-performance indoor HD LED display incorporating professional industrial design.Die cast aluminum makes it lightweight and strong. The module uses Multi-Color's newest anti-glare black LED to get a high contrast ratio. The innovative and friendly design supports a convenient installation for both hanging and stacking which makes it the ideal solution for large events, concert tours and exhibitions. The finest pixel pitch and outstanding color processing ensures a high-end performance in TV studios and lecture halls.

VG one Dimensions:


Cabinet size:576*576*84mm Weight:8.8kg


Specification:



企业微信截图_16771612828871企业微信截图_16771613246153



Product Features

1.Cabinet corner protection design,the module can be well protected during handling to prevent collision




2. Cabinet support upper and lower staggered splicing



3. Indoor/outdoor modules can be used anywhere, regardless of the left or  right;

The same cabinet can be used indoor/outdoor modules of different specifications without replacing any parts.

1

4.Use the latest optimized module connector,prevent module installation error,easier installation and more stable use





5.Patent curve lock,High precision and simple operation,able to achieve an curve of 5 ° inside and outside





Installation method:

1. Floor mounted:


2. Hoisting installation:


3. Wall installation:
