P5 320x160mm Outdoor Fixed LED Display High Refresh Rate

Outdoor Fixed Full Color LED Display, Resolution 5mm,Pixel Density/pixels/m² 40000dot/m² ,Brightness( Nits /m² ) 7000cd,Color Full-color,Full Color,RGB,1R1G1B, Module Size 320*160mm,Average Power 270W/sqm Max. Power 880W/sqm,Scan Mode 1/8S
Availability:
Quantity:
  • P5-Out/fixed

P5 full color outdoor led display high refresh rate / LED module 320x160mm

1. Fast cooling: excellent heat dissipation performance to protect the modular circuit

2. Anti-interference: Special anti electromagnetic interference function

3. High strength: support the weight 3000kg through tension test, more strength than aluminum

4. Easy installation: installed by quick lock within 20 seconds only

5. High precision: seamless splicing through CNC machining

6. Good universality: can be processed according to module drawing, used for outdoor and indoor

7. High cost-effective: large-scale production, complete production and supply chain.


Features

1. Waterproof, and great heat dissipation.
2. Can repair each led lamps, so the cost of maintain is lower, and easy to repair.
3. Big viewing angle to 140 degree at horizontal line, 140 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion.
4. To pictures and character, have clear, exquisite and real display effect.
5. High intensity and can be adjusted, so can meet the request of the customers according the application environment.
6. Clear Vivid Image Quality: even in direct , full-on sunlight to ensure you attracts more audience to get short ROI of your LED screen's investment


Application:

Widely used in stage, concert, live on TV, wedding, conference, ceremony gala, exhibition presentation, commercial advertising.


Product Specification:

Item

P5-8S

Pixel Pitch(mm)

5

Pixel Configuration

SMD2727

Physical Density(Pixels/m)

40000

ModuleSize(L×W×H)mm

320×160

Cabinet Size(LxWxH)mm

960×960x75

Brightness(cd/㎡)

6000

Gray Scale(bit)

16

AVE.Power Consumption(w/m)

<325

Module Weight(kg)

0.16

Viewing Angle

H:140°;V:140°

Control Distance

Cable100m,Multimode500m,Single mode 2km

Frame Frequency(Hz)

65

Refresh Rate(Hz)

3840

Lifetime(hrs)

100000

Input Voltage

AC110-220V/5V 60Hz

Operating Temperature/Humidity(C/RH)

Working:-20-65℃;Storage:-40-85℃/-30℃to 60℃;humidity Rh10%to 95%
